24-Hour Holter System Holter 6 Channel Touch Screen ECG Machine

24-hour holter system holter 6 channel touch screen ECG machine Sales points*Touch Screen*7 inches Color LCD display*More than 30000 patients save *Lowest price for the same quality line in China*Support SD card, USB disk  SpecificationsItemsspecificationFeatures7 "display, touch screenSupport Ecg a

Featured Products

24-hour holter system holter 6 channel touch screen ECG machine

24-Hour Holter System Holter 6 Channel Touch Screen ECG Machine




Sales points

*Touch Screen
*7 inches Color LCD display
*More than 30000 patients save
*Lowest price for the same quality line in China
*Support SD card, USB disk



 Specifications
Items
specification
Features
7 "display,
touch screen
Support Ecg analysis capabilities
Lead
standard 12 leads
lead acquisition
synchronously 12 leads
Input circuit
Floating; Protection circuit against Defibrillator effect
Input Impedance
≥50MΩ
Input circuit current
≤0.0.05μA
Record mode
Automatic: 3CH×4+1R, 3CH×4, 3CHx2+2CHx3,3CHx2+2CHx3+1R,6CHX2;
Manual: 3CH, 2CH, 3CH+1R, 2CH+1R;
Rhythm: Any lead selectable.
Filter
EMG Filter: 25 Hz / 30 Hz / 40Hz/75 Hz / 100 Hz / 150Hz
DFT Filter: 0.05 Hz/ 0.15 Hz
AC Filter: 50 Hz / 60Hz
CMRR
>100dB
Patient current leakage
<10μA
Input Circuit Current
<0.05µA
Frequency Response
0.05Hz~150Hz (-3dB)
Sensitivity
2.5mm/mV, 5 mm/mV, 10 mm/mV, 20 mm/mV
Anti-baseline Drift
Automatic
Time constant
≥3.2s
Noise level
<15μVp-p
Paper speed
12.5 mm/s, 25 mm/s, 50 mm/s
Recording mode
Thermal printing system
Paper specification
Sun-7031:80mmx20m paper roll
Sun-7062:112mmx20m paper roll
LCD display
7" graphic LCD
Safety classification
IEC60601-1 class I, type CF
Power supply
AC: 100~240V, 50/60Hz, 30VA~100VA
Fuse
AC220V±10% 2*Φ5×20mm,T2A/250V AC time lag


24-Hour Holter System Holter 6 Channel Touch Screen ECG Machine

24-Hour Holter System Holter 6 Channel Touch Screen ECG Machine


Packing and shipping

24-Hour Holter System Holter 6 Channel Touch Screen ECG Machine

1. Package: double carton boxes

2. Port: Shenzhen China, Shanghai China

3. Delivery time: 3-5 working days after receipt of payment

Payment terms

24-Hour Holter System Holter 6 Channel Touch Screen ECG Machine



 Our Services

1. Package: double carton boxes

2. Port: Shenzhen China, Shanghai China

3. Delivery time: 3-5 working days after receipt of payment

4. Payment term: T/T in advance
